TECHNICAL DATA
Output voltage at 1000 Hz, 5cm/sec.
4 mV
Channel balance at 1 kHz
1.5 dB
Channel separation at 1 kHz
22 dB
Channel separation at 15 kHz
15 dB
Frequency range
20Hz - 22,000 Hz
Frequency response
20Hz - 20,000 Hz + 3 / - 1 dB
FIM distortion at recommendedtracking force, DIN 45.542
< 1%
Tracking ability at 315Hz atrecommended tracking force
70 µm
Compliance, dynamic, lateral
25 µm/mN
Stylus type
Elliptical
Stylus tip radius
r/R 8/18 µm
Equivalent stylus tip mass
0.5 mg
Tracking force, recommended
1.75g (17.5 mN)
Tracking angle
20°
Internal impedance, DC resistance
1 kOhm
Internal inductance
580 mH
Recommended load resistance
47 kOhm
Recommended load capacitance
200-400 pF
Cartridge colour, body/stylus
Black/Black
Cartridge weight
5 g
Replacement stylus unit
Stylus 10 (a.k.a. STY-10)
