Idler Wheel 1496-05
Stock Photo - Color/Markings May Vary

Idler Wheel 1496-05

Our Part#:1496-05
Brand:GC Walsco
Idler Drive Wheel

*Required* Choose Option

Core Charge
I will mail in my old idler wheel
I have NO idler wheel to mail in [+$20.00]
1 Year Warranty
3 Year Warranty [+$6.00]
Request Stock Alert via Waiting List

Reward Points

66 points can be awarded to your webstore account (see FAQ).
General Electric GE G.E. EA97X239, EA97X581, RS3689, RS4640
Magnavox S22915 522915
Motorola 49P60018A01, 49P60081A04
Philco 35-8001-309, 61-254
RCA 108609
Voice of Music VM 22915, 35429, 42136

Found in:
Voice of Music VM V-M 1220 series, 1230 series, 1250 series, 314 and 805, etc.
RCA 110040
Zenith 907-35429

Reportedly interchangeable with 1499-42

Your order will be on hold until we receive your old idler or receive your tracking number for the package you are sending in.  Core return idler must be rebuildable and of the same type.

Currently shipping refurbished product.  It has an outer ring of new rubber fused to original factory rubber.  It is then lathed to factory spec dimensions.

Idler Wheel Specifications:
Outside Diameter (O.D.): 1.870 Inches / 47.51 mm
Inside Diameter (I.D.): .112 Inches / 2.83 mm
Overall Height: .561 Inches / 14.26 mm

Trade-in: Strong demand and limited supply means we now need your trade-in so we can supply this product line for years to come.  If we have your idler wheel in stock, we can usually accept a few clear email photos including at least one of both the top and bottom of your idler wheel and a tracking number of the padded secure package in which your trade-in was sent.  In return, you may receive a rebuild, a rejuv, or N.O.S. as the case may be.

Warranty:  We warranty our idler wheels not to be the cause of incorrect speed or speed fluctuations for 1 year.  Abuse such as exposure to petroleum products or other customer 'hacks' such as drilling out the center hole to force its use in a non-sanctioned machine, voids warranty.  Warranty compensation limited to the store's choice of product replacement, repair or pro-rated web-store credit and requires that you securely mail in the idler wheel in question.  No cash refunds after 90 days.

Replacement tips: An often overlooked source of idler wheel troubles other than the obvious deterioration of the rubber is the often dried lubrication on the shaft upon which the wheel is mounted.  Sometimes an idler wheel will be completely seized as a result.  Clean both the shaft and the idler wheel hole usually with a Q-tip.  Generally isopropyl alcohol for cleaning followed by a tiny amount of new automotive wheel bearing grease or similar are the common products of choice.  This step is so valuable that sometimes it can significantly delay the need to replace the idler wheel.  Of course, avoid petroleum product contact with the rubber at all cost.  Finally, always, always make sure to clean the rubber idler wheel contact surfaces with lanolin-free isopropyl alcohol (or similar) prior to installing your replacement idler wheel.  Do this even if the surface looks 'clean'.  Enjoy the music.
